Description
Product Code : 001
Our model DAW- 931 self propelled combine harvester has been tested for commerical purpose by Govt of INDIA, Ministry of Agricultre (Dept. of Agriculture and Corporation) Northern Region Farm Machinery Trainng and Testing Institute, Tractor Nagar, Sirsa Road, Hissar 125001 Haryana. We also provide bank loan facility for our harvester combines
Technical Specifications of daw - 931
AL 412 TAC 3/1
| Engine |
|---|
| Make |
Ashok Leyland |
|---|
| Model |
|
|---|
| RPM |
2200 |
|---|
| Engine |
|---|
| Make |
Ashok Leyland |
|---|
| Model |
AL 412 TAC 3/1 |
|---|
| RPM |
2200 |
|---|
| Starting System |
|---|
| Starter |
Bosch India |
|---|
| Alternator |
Lucas - TVS |
|---|
| Cylinder |
|---|
| Number |
Six |
|---|
| Disposition |
Vertical Inline |
|---|
| Battery |
|---|
| Make |
EXCIDE |
|---|
| Pipe |
Lead ACID |
|---|
| No. of Batteries |
2 Batteries |
|---|
| Assembling system |
|---|
| Threshing Drum Width |
1270 mm |
|---|
| Outside Dia |
600 |
|---|
| Straw Walker |
|---|
| Number |
5 |
|---|
| Types |
Closed Rack Type serrated size edges with 6 Steps on each straw walker |
|---|
| Length |
3850 mm |
|---|
| Width |
191 mm / 230 mm |
|---|
| Cleaning Sieves |
|---|
| No. of Sieves |
2 |
|---|
| Types |
Open Lip Frog Mouth |
|---|
| Overall Size of Sieves | Front | Reaar |
|---|
| Length |
1525 (mm) |
630 (mm) |
|---|
| Width |
1220 (mm) |
1220 (mm) |
|---|
| Capacity |
|---|
| Grain Tank |
1900 Kg. Wheat |
|---|
| Hydraulic Tank |
30 Ltr. |
|---|
| Fuel Tank |
360 Ltr. |
|---|
| Tyres |
|---|
| Front |
(18.4 - 30) 14 PR |
|---|
| Rear |
(9 - 00 - 16) 16 PR |
|---|
| output |
|---|
| Wheat |
2.5 to 4 Acres per Hour |
|---|
| Paddy |
2 to 3 Acres per Hour |
|---|
| Cutting Bar Size |
|---|
| Working Width with Shoes |
4300 (mm) |
|---|
| Effective Cutter Bar Width |
4280 (mm) |
|---|
| No. & Spacing of Knife guards |
58 (29 Pairs) |
|---|
| No. & Types of Knife Blades |
58 Serrated |
|---|
| Dimensions |
|---|
| Dimensions | Working | Transport |
|---|
| Length |
7060 (mm) |
12370 (mm) |
|---|
| Width |
6205 (mm) |
2930 (mm) |
|---|
| Height |
3840 (mm) |
3840 (mm) |
|---|
